Simrad NSS4-12 12 MFD – No Sonar
The Simrad NSS4-12 provides a 12-inch multifunction display without sonar for compatible marine electronics installations. Its larger screen supports clearer chart and system-data presentation, helping operators manage navigation information while retaining flexibility to add a separate transducer and sounder module.
$2,279.00
In Stock
Simrad NSS4-12 12 MFD - No Sonar Specs
| Brand | Simrad |
| Model Name | NSS12 Evo4S (NSS4-12) |
| Part Number/SKU | 000-16276-001 |
| Technology Category | Performance Multifunction Display |
| Display Size & Type | 12" SolarMAX HD IPS Touchscreen |
| Resolution | 1280 x 800 pixels |
| Brightness | 1200 nits |
| Processor/Engine | Qualcomm 8-Core Processor |
| Operating System | Simrad NOS (Neo Interface) |
| Sonar Compatibility | N/A (No internal sonar; Network sonar support via S3100/S5100) |
| Mapping/Charts | Worldwide Basemap (C-MAP Discover X/Reveal X Compatible) |
| NMEA Interface | NMEA 2000 (Micro-C) |
| Networking Ports | 1x Ethernet Port (X-Coded GbE), 1x Ethernet (5-pin), 1x USB |
| Wireless | Wi-Fi 5, Bluetooth 4.0 |
| Voltage Input | 12/24 V DC (10 - 31.2 V DC) |
| Power Draw | 40W Max |
| Waterproofing | IPX6 & IPX7 |
| Physical Dimensions | 339 x 208 x 85 mm |
| Cut-out Dimensions | 311 x 194 mm |
| Weight | 2.8 kg |
| Country of Origin | Made in Mexico |
| Standard Warranty | 2 Years |
